Rev 1.3 Series X11CA Computer Annunciators: X11CA Configuration Software User’s Manual

4. X11CA Software Operation

If you place the cursor underneath each icon, its name will display under the icon.

Name

Description

New

Opens a new configuration file. Pressing this button also resets the

Configuration Software

Open

Opens a window that has a list of existing files to be selected from.

Save

Saves the current properties into the currently open configuration
file.

Properties

Opens a Module Properties window of the selected logical
module. See Figure 4-14. Module Properties Window.

Connect

Makes connection between logical modules and their
corresponding physical alarm modules. The logical module that
failed to establish communication with its physical module
displays ‘NoComm’ message in its cell.

Disconnect

Disconnects logical modules from their physical alarm modules.

Run

Same as the Run submenu of System menu.

Stop

Same as the Stop submenu of System menu.

Program

Same as the Program submenu of the Module menu.

Receive

Same as the Receive submenu of the Module menu

Table 4-6 Tool Bar

4.2.4 System Display Field

The System Display area is composed of three fields.
§ Module Display table field
§ Module Status field
§ Push Button Field

Example: Figure 4-7 System Display Field shows System Display area with 225
logical modules. The number in each cell is its logical module addresses. When the
logical module cell number 225 is selected, its module number, its status, and
sequence types of its channels display on the Module Status area.
