Rev 1.3 Series X11CA Computer Annunciators: X11CA Configuration Software User’s Manual

4. X11CA Software Operation

Example: If you have three alarm modules, you can set the width to 1 and the
high to 3, or the width to 3 and the high to 1.

Test Types

This function is for testing the properties of physical alarm modules. For
testing see Section 4.11Testing Alarm Modules .

There are two types of testing depending on the switch setting on the X11CA-
IM.

§ When the switch on the X11CA-IM is on PRGM side, use the push

buttons on the right side of the Main window in the Configuration
Software environment.

§ When the switch on the X11CA-IM is on RUN side, use the test buttons

attached to the X11CA-IM.

Choose from the following two options.

Test Types

Description

Operational Test

Tests lamplight and sequence of each channel.

Lamp Test only

Tests lamplight of each channel only.

Table 4-10 Test Type

For Configuration Software test procedure, see Section 4.11 Testing Alarm
Modules.

Horn1& Horn2 SilenceType

There are four silence types for each horn.

NOTE:
This function will be available in the Configuration Software environment in
the future. At present, it is enabled only when the X11CA-IM is in RUN
mode.
