Rev 1.3 Series X11CA Computer Annunciators: X11CA Configuration Software User’s Manual
4. X11CA Software Operation
Hardware Control-© 2003 Ronan Engineering 14
Submenu Description
Config Opens Module Properties window.
(See
Figure 4-14. Module Properties Window .)
This function is same as the Config submenu of Module menu.
Connect Makes connection between the logical modules and the physical
modules.
Disconnect Disconnects from the physical modules.
Run Each logical module cell on the Main window that has communication
with its physical module becomes green and displays ‘Run’ message.
(See Figure 4-33. Modules in Run Mode.)
If connection to the physical modules is active, the physical module is
ready to be tested.
The logical module that fails to establish communication with its
physical module displays the message, ‘NoComm’ displays on its
white cell.
Stop Each logical module cell on the Main window displays ‘Stop’ message
over the red background.
(See Figure 4-34 Modules in Stop Mode.)
If connection to the physical modules is active, its physical module is
ready for programming or for sending a copy of its properties to its
logical module.
The logical module that fails to establish communication with its
physical module displays the message, ‘NoComm’ displays on its
white cell.
Receive If connected, the logical modules that are in Stop mode receive copies
of properties from their physical modules.
The logical module that fails to establish communication with its
physical module displays the message, ‘NoComm’ displays on its
white cell.
Program If connected, and the logical modules are in Stop mode, an authorized
user can program properties of the logical modules into their
corresponding physical modules.
The logical module that fails to establish communication with its
physical module displays the message, ‘NoComm’ displays on its
white cell.
SaveReportAs Opens a Save As window where the system report file name can be
changed.
PrintReport Sends the content of currently open report file to the default printer.
Table 4-3 System Submenu
