Rev 1.3 Series X11CA Computer Annunciators: X11CA Configuration Software User’s Manual
4. X11CA Software Operation
Hardware Control-© 2003 Ronan Engineering 19
Figure 4-8. Push
Button Field
PB Buttons
T Test
S Silence
A Acknowledge
R Reset
F.R. First Out
Reset
GF1 General
Function 1
GF2 General
Function 2
4.2.5 Status Bar
Status
Settings This area displays the communication port settings, such
as baud rate, parity, data bits, and stop bit.
Table 4-8. Status Bar
4.3 Configuring Communication Properties
In order for the Configuration Software to communicate with physical alarm
modules, speed and port of the host computer must be set up.
4.3.1 Setting the Communication Port
The communication port is set on the Setup window. The data format is eight data
bits, none parity and one stop bit.
1) Click on the Setup menu and then the Comport submenu to open the Setup
window.
