Rev 1.3 Series X11CA Computer Annunciators: X11CA Configuration Software User’s Manual
4. X11CA Software Operation
Hardware Control-© 2003 Ronan Engineering 34
§ When the Field Contact is in an alarm
condition, transistor output turns OFF.
§ When the Field Contact returns to normal
condition, transistor output turns ON.
ACK
(
Acknowledge )
If the input is normally not energized:
§ When the Field Contact goes into an
alarm condition, transistor output turns
ON.
§ When the alarm is acknowledged,
transistor output turns OFF.
If the input is normally energized
§ When the Field Contact goes into alarm
condition, transistor output turns OFF
§ When the alarm is acknowledged,
transistor output turns ON.
ALARM
(
Alarm Simulator )
If the input is normally not energized:
§ When the Field Contact goes into alarm
condition, transistor output turns ON.
§ When the alarm is acknowledged,
transistor output stays ON.
§ When the alarm returns to normal,
transistor output goes OFF.
If the input is normally energized:
§ When the Field Contact goes into alarm
condition, transistor output turns OFF.
§ When the alarm is acknowledged,
transistor output stays OFF.
§ When the alarm returns to normal,
transistor output turns ON.
HORN 1& 2
If the input is normally not energized:
§ When the Field Contact goes into alarm
condition, the audio device becomes
active.
§ When the silence button connected to the
X11CA-IM is pressed, the audio display
turns OFF
