Rev 1.3 Series X11CA Computer Annunciators: X11CA Configuration Software User’s Manual
4. X11CA Software Operation
Hardware Control-© 2003 Ronan Engineering 28
NOTE:
To adjust a cell size, position the cursor over the dividing line until the bi-
directional arrow symbol (
? ) appears and then drag the cursor in the
direction you want to stretch or shrink.
4.4.2 Setting Module Properties
Setting new module properties can be done on the Module Properties window.
There are two ways to open it.
1) Click on the Module menu, and then Config. (Or and then .)
2) Or double-click in each module cell of the Module Display window to set the
properties.
The Module Properties window will show the default values of the module.
Figure 4-14.
Module
Properties
Window
On the Module Properties window, there are two main fields: Channels
Properties field and Common Signals field.
4.5.2.1 Setting Channel Properties
The Channel Properties field is on the left side of the Module Properties
window. The list box at the top of the field displays the properties of each
channel.
