Rev 1.3 Series X11CA Computer Annunciators: X11CA Configuration Software User’s Manual
4. X11CA Software Operation
Hardware Control-© 2003 Ronan Engineering 15
SETUP (ALT+E) menu
Submenu Description
CommPort Opens Setup window where you can set up the communication port
and its baud rate.
(See
Figure 4-9 Communication Port Window .)
Password Opens Set Password window where you can change the password for
programming the micro-controllers. (See
Figure 4-40. Set Password
Window .)
Table 4-4 Setup Submenu
HELP (ALT+H) menu
Submenu Description
About Opens About X11CA window that displa ys the information about the
software, such as the version number.
Figure 4-5
About
Submenu
Table 4-5 Help Submenu
4.2.3 The Tool Bar
The third line from the top of the Main window is the tool bar.
Figure 4-6 Icons
