4. X11CA Software Operation
Hardware Control-© 2003 Ronan Engineering 46
?
A ‘Run’ message displays in the green cell of each active module cell.
? A ‘N.C’ message displays in the white cell of each inactive module.
? The Stop icon ( ) turns red.
? On each module status cell, the module number and its status display.
? On the status area, the com port settings display
? The Push Button field displays at the right side of the window.
? The Disconnect icon ( ) becomes active.
4.7 Stopping Physical Modules from Running
The logical modules must be in Stop mode to perform one of the following cases.
? To program logical module properties into the physical modules.
? To retrieve the physical module properties into the logical module properties.
Follow the instructions below to stop the physical modules from running.
1) Click on the Stop icon ( ) to stop receiving Field Contact inputs.
2) Click on the System menu and then stop to stop all modules. ( then
key).
3) Or click on the Module menu and then the Stop submenu to stop a single
module. ( then key).
