Rev 1.3 Series X11CA Computer Annunciators: X11CA Configuration Software User’s Manual
4. X11CA Software Operation
Hardware Control-© 2003 Ronan Engineering 26
Serial Data Output Type: Data output follow
Serial Data Output is the signal that is transmitted from TXD (transmittal data
line) of the Port 2 on the X11CA-IM when X11CA-IM is in RUN mode.
Example: The following table is based on the A-1 sequence type running in the
X11CA-IM environment. The sequence chart is available on the CD provided.
Data Output Follow Description
FC
(Field Contact)
If the Field Contact input is normally not energized:
§ When the Field Contact goes into alarm condition,
the output signal is energized.
§ When the Field Contact returns to normal condition,
the output signal becomes de-energized.
If the Field Contact input is normally energized
§ When the Field Contact is in alarm condition, the
output signal becomes de-energized.
§ When the Field Contact returns to normal condition,
the output signal becomes energized
ACK
(Acknowledge)
If the Field Contact input is normally not energized:
§ When the Field Contact goes into alarm condition,
the output signal becomes energized.
§ When the alarm is acknowledged, the output signal
becomes de-energized.
If the Field Contact input is normally energized
§ When the Field Contact goes into alarm condition,
the output signal becomes de-energized.
§ When the alarm is acknowledged, the output signal
becomes energized.
ALARM
(Alarm Simulator)
If the Field Contact input is normally not energized:
§ When the Field Contact goes into alarm condition,
the lamp turns ON and, the output signal becomes
energized.
§ The lamp and the data output signal stay active until
the alarm is acknowledged. After that, the alarms
return to normal and then reset.
If the Field Contact input is normally energized:
§ When the Field Contact goes into alarm condition,
the lamplights turn OFF and, the output signal
becomes de-energized.
§ The lamp and the data output signal stay inactive
