Rev 1.3 Series X11CA Computer Annunciators: X11CA Configuration Software User’s Manual
4. X11CA Software Operation
Hardware Control-© 2003 Ronan Engineering 13
Submenus Description
Config
Opens Module Properties window.
(See Figure 4-14. Module Properties Window.)
Run
The highlighted logical module cell on the Main window that has
communication with its physic al module becomes green and displays
‘Run’ message.
(See Figure 4-33. Modules in Run Mode.)
If connection to the physical modules is active, the physical module is
ready to be tested.
The logical module that fails to establish communication with its
physical module displays the message, ‘NoComm’ displays on its
white cell.
Stop
The highlighted logical module cell on the Main window displays
‘Stop’ message over the red background.
(See Figure 4-34 Modules in Stop Mode.)
If connection to the physical modules is active, its physical module is
ready for programming or for sending a copy of its properties to its
logical module.
The logical module that fails to establish communication with its
physical module displays the message, ‘NoComm’ displays on its
white cell.
Receive
If connected and the highlighted logical module is in Stop mode, it
receives properties from its physical module.
The logical module that fails to establish communication with its
physical module displays the message, ‘NoComm’ displays on its
white cell.
Program
If connected, and the highlighted logical module is in Stop mode, an
authorized user can program properties of a logical module into its
physical module.
The logical module that fails to establish communication with its
physical module displays the message, ‘NoComm’ displays on its
white cell.
Table 4-2 Module Menu and Its Submenus
SYSTEM (ALT+S) menu
Unlike the Module menu, the System menu applies to all the modules in the
system.
