APPENDIX B - DISPLAYED CHARACTER SET
APPENDIX B
DISPLAYED CHARACTER SET
The Application builder allows any character in the ASCII range of 0 to 127 (decimal 32 to 126 can be entered
through the normal keyboard characters). Of this set, many will display as blank or some other symbol. The
set usable from the instrument front face is indicated by a †. The table below shows the complete displayed
character set for the range 0 to 127.
CAUTION. The instrument does not check communications messages from other devices that may send
ascii data for display. If ascii data exceeds the valid range of 0 to 127, the display may behave erratically
or lock up. DO NOT USE ASCII DATA IN THE RANGE OF 128 TO 255 FOR DISPLAY!
Decimal Keyboard Display
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Decimal Keyboard Display
19
20
21
22
(space
indicator)
23
24
25
26
27
28
29
30
31
32 † space
33 !
34 “
35 † #
36 $
37 † %
Decimal Keyboard Display
38 &
39 '
40 (
41 )
42 † *
43 † +
44 ,
45 † -
46 .
47 † /
48 † 0
49 † 1
50 † 2
51 † 3
52 † 4
53 † 5
54 † 6
55 † 7
56 † 8
