s
peCIfICatIons
Standard StrongArmPark DC 10 StrongArmPark DC 14 Solar
Arm Length Capacity 10 ft (3 m) 14 ft (4.3 m)
Field Adjustable
Open/Close Time Three speeds: 1.5, 2, and 2.5
seconds Three speeds: 2.5, 3, and 3.5
seconds
Full Open Angle Adjustable 90°± 10° Adjustable 90°± 10°
Handing
Left handing standard. Easy to
convert to right handing in field. Left handing standard.
Right handing optional.
Maximum Gate/Arm Load
8 lbs/3.6 kg at 10 ft/3 m
(0.8 lbs per foot, 0.4 kg per 30 cm) 11.2 lbs/5 kg at 15 ft/4.3 m
(0.8 lbs per foot, 0.4 kg per 30 cm)
Power: Single Phase
(switch selectable) 115 Volts, 3 amps, 50/60 Hz
230 Volts, 1.5 amps, 50/60 Hz 115 Volts, 3 amps, 50/60 Hz
230 Volts, 1.5 amps, 50/60 Hz
24VDC
Duty Cycle Continuous Continuous Continuous
Accessory Power 1A each at 12VDC, 24VDC & 24VAC 1A each at 12VDC, 24VDC & 24VAC 1A each: 12VDC & 24VDC
DC Batteries Two 12VDC, 8Ah batteries. Field configurable to fail open or secure (close) when batteries deplete.
Programmable Output Relays
Two configurable user relays: 30VDC, 3A Solid State and 250VAC, 10A electromechanical.
Optional: Extended Relay Module (8 ports)
User Controls Smart DC Controller (32 character LCD display, 5 tact buttons). S.T.A.R.T. software with PC laptop.
Communication USB, RS-232, RS-485
Temperature Rating -13°F to 158°F (-25°C to 70°C) No heater necessary.
UL 325 Compliant Usage Class I,II, III, IV
Limited Warranty Operator: 2 years
Copyright Notice
© Copyright 2013 by HySecurity Gate, Inc.
All rights reserved. No part of this manual may be reproduced by any means (photocopier, electronic, or mechanical), without the express
written permission of HySecurity Gate, Inc. Federal copyright law prohibits the reproduction, distribution, or public display of copyrighted
materials without the express written permission of the copyright owner, unless fair use or other exemption under copyright law applies.
Additionally, HySecurity Gate, Inc. makes no representations or warranty with respect to this manual. We also reserve the right to make
changes in the products described without notice and without any obligation to notify any persons of any such revision or change.
Trademarks
StrongArmPark DC, SwingSmart DC, SlideSmart DC, StrongArm M30, StrongArm M50, StrongArm, SlideDriver, SwingRiser, HydraSwing,
HydraLift, SlideWinder, Smart DC Controller, Smart Touch Controller, S.T.A.R.T. and the HySecurity logo are trademarks or registered
trademarks of HySecurity Gate, Inc.
D0536 Rev. B Specifications 800-321-9947 www.hysecurity.com © 2013
