Additional mechanical relay options are shown in Table 5. Any of the options can be configured through the
relays on the Smart DC Controller. If you need additional mechanical relay terminals, an optional extended relay
module with 8 terminals is available from HySecurity.
NOTE: System baud rate: 38,400
Programmable User Relays: Table 5
StrongArmPark DC Revenue Control Parking Application
Relay No. Name Description Wire Connection
29
Outer Arming Loop Active Output
OALD Input. Interlocks an entry device to prevent
pedestrian use. This output is active whenever the
Outer Arming Loop Detector is tripped. NOTE: If
the Center Loop is tripped before the Outer Arming
Loop (indicating a vehicle is exiting the facility), this
relay will not energize. R1, R3 through R10
30
Inner Arming Loop Active Output
IALD If the Center Loop is tripped before the Inner Arming
Loop (indicating a vehicle is entering the facility), this
relay will not energize. R1, R3 through R10
31
Device Reset Pulse Output N.O. Input. A 250ms pulse occurs when the Center
Loop is triggered. If a back out occurs, this relay
sends a reset pulse to the access control device or
computer system to invalidate the ticket. R1, R3 through R10
32
Back Out Pulse Output N.O. Input. The relay outputs a 250ms pulse when a
back out has occurred based on the criteria given in
the “Revenue Control Parking Functions.” R1, R3 through R10
33
Inbound Transient/Lot Output N.O. Input. The relay outputs a 250ms pulse used to
increment the transient and total vehicle counts. R1, R3 through R10
TRANSIENT USER
34
Outbound Transient/Lot Output N.O. Input. The relay outputs a 250ms pulse used to
decrement the transient and total vehicle counts. R1, R3 through R10
TRANSIENT USER
35
Inbound Tenant Output N.O. Input. The relay outputs a 250ms pulse and
increments the tenant counter when the Tenant User
input is activated and OALD, then CLD, are tripped
and released. This activity signals a prepaid customer
has entered the facility. R1, R3 through R10
TENANT USER
36
Outbound Tenant Output N.O. Input. The relay outputs a 250ms pulse and
decrements the tenant counter when the Tenant
User input is activated and IALD, then CLD, are
tripped and released. This activity signals a prepaid
customer has exited the facility. R1, R3 through R10
TENANT USER
37
Inbound Special Output N.O. Input. The relay outputs a 250ms pulse and
increments the special counter when the SPECIAL
USER input is activated and OALD, then CLD, are
tripped and released. This activity signals a customer
has entered the facility. R1, R3 through R10
SPECIAL USER
