SDC Inputs & Wiring
This section provides information about the Smart DC Controller, its inputs for peripheral connections, and its
monitoring capabilities. This section explains how to:
• Make Connections on the Smart DC Controller
• Integrate with Security Systems
• Connect HY-5A Vehicle Detectors
• Connect Accessory Devices
Š Entrapment Sensor Connections
Š Access Controls
Š User Relays
