Installer Menu Setting Options Menu Tasks & Explanations SDC Wire
Connections
OR 1 REVERSE
Outer Arm Loop 0 = Pause closing only
1 = Enable reversing to open
2 = Ignore and continue closing The default is for full reversal when the Inner
Arming Loop is triggered. A setting of 0 causes
the barrier arm to only pause when triggered.
Closure begins as soon as the loop is clear again.
A setting of 2 is provided for the most secure
facilities where it is essential that the loop trigger
is completely ignored and the barrier arm contin-
ues closing without pause or reversal. OUT OBS LOOP
(OUTER ARMING)
COM or connection
to HY-5A detector
IR 1 REVERSE
Inner Arm Loop 0 = Pause closing only
1 = Enable reversing to open
2 = Ignore and continue closing The default is for full reversal when the Inner
Arming Loop is triggered. A setting of 0 causes
the barrier arm to only pause when triggered.
Closure begins as soon as the loop is clear again.
A setting of 2 is provided for the most secure
facilities where it is essential that the loop trigger
is completely ignored and the barrier arm contin-
ues closing without pause or reversal. IN OBS LOOP
(INNER ARMING)
COM or connection
to HY-5A detector
DL 1 STANDARD
Detector Logic 1 = Standard
2 = Quick Close Configures for faster closure. This selection
determines whether the close timer begins to
count after vehicles have departed the detector
loops or whether the close timer will count down
while the loops are occupied.
The default setting 1 causes the Close Timer to
start when the Center Loop is clear. A setting of
2 causes the Close Timer to start when the open
limit switch trips. Center Loop
COM or connection
to HY-5A detector
CR 0 REVERSE
Center Loop 0 = Reopen if center loop triggers
1 = Pause only The default allows the barrier arm to reopen if
the Center Loop detector is triggered during
closure of the barrier arm. A setting of 1 causes
the barrier arm to only pause when triggered.
Closure begins as soon as the loop is clear again. Center Loop
COM or connection
to HY-5A detector
CB 0 (OFF)
CLD Disable ELD 0 = Normal operation of Free Exit
1 = Disable Free Exit Setting 1 allows an CLD input to disable the Free
Exit Detector (ELD) until the barrier arm is fully
closed. Used in bi-directional traffic situations. Center Loop
COM or connection
to HY-5A detector
CP 0 (OFF)
CLD Counts PBO
0 = Immediate closure
1 = Provides addt’l open time The default allows the Center Loop Detector
when triggered and released, to close the barrier
arm immediately. The optional setting of 1 des-
ignates that the Smart DC Controller remember
an additional open command if the open input
is activated a second time while the barrier arm
remains open. (For example, to prevent a vehicle
from being stranded). Center Loop
COM or connection
to HY-5A detector
EB 0 (OFF)
ELD Backoff 0 = Normal operation of Free Exit
1 = Back off close function The default allows normal latch open operation
of the Free Exit detector. The optional setting of
1, creates an automatic close function if a vehicle
triggers and then backs off the Free Exit Loop
detector. Free Exit Loop
COM or connection
to HY-5A detector
RL 1 0 DISABLED
Relay 1 Logic 0 = Disabled
1 to 38 available
Configures the function of the User 1 output
relay. It has the capacity to switch both AC and
DC loads and can be used for high voltage and/
or high current loads. Connect devices directly to
the top of the relay: COM and either NO and/or
NC contacts.
Multiple logic function options exist. See “User
Relays - Programming Procedure” on page 6-8. COM
User 1 Relay
