3-10 D0536 Rev. B StrongArmPark DC: Programming & Operations Manual www.hysecurity.com
Installer Menu Setting Options Menu Tasks & Explanations SDC Wire
Connections
RL 2 0 CLOSE LIMI
Relay 2 Logic 0 = Disabled Relay 2 configures the function of the User 2
output relay, which is an electronic relay with the
capacity for switching a DC load only.
NOTE: In the StrongArmPark DC, it is recom-
mended to use the User 2 Relay for connection
to the LED arm lighting. COM
User 2 Relay
RL 3 0 DISABLED
thru
RL 10 0 DISABLED
Relay Logic 0 = Disabled
1 to 38 available
Similar to Relay 1 Logic. COM
User 3 through 10
Relay
TL 2 (45 SECS)
Open Time Alert 2 = 45 second delay
0 = 0s delay
1 = 15s
3 = 75s
4 = 105s
5 = 135s This menu item only appears if the #8 User
Relay function has been selected. It adjusts the
time delay before activation of the User Relay
function. User Relay
LT 3 (75 SECS)
Loitering Alert 3 = 75 second delay
0 = 0s delay
1 = 15s
2 = 45s
4 = 105s
5 = 135s This menu item only appears if the #13 User
Relay function has been selected. It adjusts the
time delay before activation of the User Relay. User Relay
SA 0 (OFF)
SDC Address
0 = No network
1 to 99 = Network “drop” address Sets the system address for network
communication: 0 = no network communication
1-99 sets individual poling addresses.
See PD SET PASSWORD in “User Menu: Table
1.” on page 3-4. RS-485. Involves ad-
ditional hardware &
software.
ELD0 RUN MODE
Exit Loop Set 0 = Run mode
1 = Show frequency
2 = Show call level 0-7
3 = Set Frequency Controls the HY-5A Free Exit loop detector. HY-5A
ILD0 RUN MODE
In Arm Loop Set 0 = Run mode
1 = Show frequency
2 = Show call level 0-7
3 = Set Frequency Controls the HY-5A Inside Obstruction Loop
(Inner Arming Loop) detector. HY-5A
OLD0 RUN MODE
Out Arm Loop Set 0 = Run mode
1 = Show frequency
2 = Show call level 0-7
3 = Set Frequency Controls the HY-5A Outside Obstruction Loop
(Outer Arming Loop) detector. HY-5A
CLD0 RUN MODE 
Center Loop Set
0 = Run mode
1 = Show frequency
2 = Show call level 0-7
3 = Set Frequency Controls the HY-5A Center Loop detector. HY-5A
