Description of the data path
MARLIN Technical Manual V2.4.0
79
Register Name Field Bit Description
0xF0F00804 AUTO_EXPOSURE Presence_Inq [0] Presence of this feature:
0: N/A
1: Available
Abs_Control [1] Absolute value control
O: Control with value in the value field
1: Control with value in the absolute
value CSR
If this bit= 1 the value in the value field
has to be ignored
--- [2..4] Reserved
One_Push [5] Write: Set bit high to star
Read: Status of the feature:
Bit high: WIP
Bit low: Ready
ON_OFF [6] Write: ON or OFF this feature
Read: read a status
0: OFF
1: ON
A_M_MODE [7] Write: set mode
Read: read current mode
0: MANUAL
1: AUTO
--- [8..19] Reserved
Value [20..31] Read/Write Value
This field is ignored when writing the
value in Auto or OFF mode.
If readout capability is not available
reading this field has no meaning
Table 32: CSR: Auto Exposure
Note
L
Configuration
To configure this feature in an advanced register: See Table
116: Advanced register: Auto gain control on page 221.
