Description of the data path
MARLIN Technical Manual V2.4.0
77
When both auto shutter and auto gain are enabled, priority is given to
increasing shutter when brightness decreases. This is done to achieve the
best image quality with lowest noise.
For increasing brightness, priority is given to lowering gain first for the same
purpose.
Note
L
• Values can only be changed within the limits of shutter
CSR.
• Changes in auto exposure register only have an effect
when auto shutter is enabled.
• Auto exposure limits are: 50..205 (SmartView Ctrl1
tab: Target grey level)
