Camera interfaces
MARLIN Technical Manual V2.4.0
58
IO_OUTP_CTRL 1-2
The outputs (Output mode, Polarity) are controlled via two advanced feature
registers (see
Table 24: Advanced register: Output control on page 58).
The Polarity field determines whether the output is inverted or not. The out-
put mode can be viewed in the table below. The current status of the output
can be queried and set via the PinState.
From firmware 2.03 onwards it is possible to read back the status of an out-
put pin regardless of the output mode. This allows for example the host com-
puter to determine if the camera is busy by simply polling the BUSY output.
Note
L
Outputs in Direct Mode:
For correct functionality the Polarity should always be set
to 0 (SmartView: Trig/IO tab, Invert=No).
Register Name Field Bit Description
0xF1000320 IO_OUTP_CTRL1 Presence_Inq [0] Indicates presence of this
feature (read only)
--- [1..6] Reserved
Polarity [7] 0: Signal not inverted
1: Signal inverted
--- [8..10] Reserved
Output mode [11..15] Mode
see Table 25: Output routing
on page 59
--- [16..30] Reserved
PinState [31] RD: Current state of pin
WR: New state of pin
0xF1000324 IO_OUTP_CTRL2 Same as
IO_OUTP_CTRL1
Table 24: Advanced register: Output control
