Configuration of the camera
MARLIN Technical Manual V2.4.0
207
Maximum resolution
This register indicates the highest resolution for the sensor and is read-only.
This register normally outputs the MAX_IMAGE_SIZE_INQ Format_7 Mode_0
value.
0xF1000044 ADV_INQ_2 Input_1 [0]
Input_2 [1]
--- [2] Reserved
--- [3..7] Reserved
Output_1 [8]
Output_2 [9]
--- [10] Reserved
--- [11..15] Reserved
IntEnaDelay [16]
--- [17] Reserved
--- [18..31] Reserved
0xF1000048 ADV_INQ_3 --- [0..31] Reserved
0xF100004C ADV_INQ_4 --- [0..31] Reserved
Note
L
This register normally outputs the MAX_IMAGE_SIZE_INQ
Format_7 Mode_0 value.
This is the value given in the specifications tables under
Picture size (max.) in Chapter
Specifications on page 38.
Register Name Field Bit Description
0xF1000200 MAX_RESOLUTION MaxHeight [0..15] Sensor height
(read only)
MaxWidth [16..31] Sensor width
(read only)
Table 101: Advanced register: Maximum resolution inquiry
Register Name Field Bit Description
Table 100: Advanced register: Advanced feature inquiry
