Configuration of the camera
MARLIN Technical Manual V2.4.0
224
Mirror image
The table below illustrates the advanced register for Mirror image.
Soft Reset
The SOFT_RESET feature is similar to the INITIALIZE register, with the follow-
ing differences:
• 1 or more bus resets will occur
• the FPGA will be rebooted
The reset can be delayed by setting the Delay to a value unequal to 0 - the
delay is defined in 10 ms steps.
Note
L
Trigger delay works with external trigger modes only.
Register Name Field Bit Description
0xF1000410 MIRROR_IMAGE Presence_Inq [0] Indicates presence of this
feature (read only)
--- [1..5] Reserved
ON_OFF [6] Mirror image on/off
1: on
0: off
Default: off
--- [7..31] Reserved
Table 121: Advanced register: Mirror
Register Name Field Bit Description
0xF1000510 SOFT_RESET Presence Inquiry [0] Read only
--- [1..5] Reserved
Reset [6] Initiate reset
--- [7..19] Reserved
Delay [20..31] Delay reset in 10 ms steps
Table 122: Advanced register: Soft reset
