Configuration of the camera
MARLIN Technical Manual V2.4.0
202
0XF1000260 DEFERRED_TRANS See Table 109: Advanced register: Deferred image
transport on page 215
0XF1000270 FRAMEINFO See Table 110: Frame information register on page
216
0XF1000274 FRAMECOUNTER See FRMCNT_STAMP
0XF1000280 HDR_CONTROL MARLIN F-131x only
See Table 111: High dynamic range configuration
register on page 217
0XF1000284 KNEEPOINT_1
0XF1000288 KNEEPOINT_2
0XF100028C KNEEPOINT_3
0XF1000290 DSNU_CONTROL MARLIN F-131B only; Firmware 2.02
See Table 112: Advanced register: DSNU on page
218
0XF1000294 BLEMISH_CONTROL MARLIN F-131x only; Firmware 2.02
See Table 113: Advanced register: Blemish on
page 219
0XF1000300 IO_INP_CTRL1 See Table 18: Advanced register: Input control on
page 53
0XF1000304 IO_INP_CTRL2
0XF1000308 IO_INP_CTRL3 Dolphin series only
0XF1000320 IO_OUTP_CTRL1 See Table 24: Advanced register: Output control
on page 58
0XF1000324 IO_OUTP_CTRL2
0XF1000328 IO_OUTP_CTRL3 Dolphin series only
0XF1000340 IO_INTENA_DELAY See Table 114: Advanced register: Delayed Inte-
gration Enable (IntEna) on page 220
0XF1000360 AUTOSHUTTER_CTRL MARLIN/OSCAR series only
See Table 115: Advanced register: Auto shutter
control on page 221
0XF1000364 AUTOSHUTTER_LO
0XF1000368 AUTOSHUTTER_HI
0XF1000370 AUTOGAIN_CTRL MARLIN/OSCAR series only
See Table 116: Advanced register: Auto gain con-
trol on page 221
0XF1000390 AUTOFNC_AOI MARLIN/OSCAR series only
See Table 117: Advanced register: Autofunction
AOI on page 222
0XF10003A0 COLOR_CORR MARLIN/OSCAR CCD type color cameras only
See Table 119: Advanced register: Color correction
on page 223
Register Register name Description
Table 97: Advanced registers summary
