Configuration of the camera
MARLIN Technical Manual V2.4.0
219
Having generated the correction data it is possible to separately control the
blemish pixel correction with the help of the following register:
Input/output pin control
Register Name Field Bit Description
0xF1000294 BLEMISH_CONTROL Presence_Inq [0] Indicates presence of this
feature (read only)
ComputeError [1] see DSNU_CONTROL
--- [2..3]
ShowImage [4] see DSNU_CONTROL
ComputeData [5] see DSNU_CONTROL
ON_OFF [6] blemish correction On/Off
ON: High
Default: OFF
Busy [7] see DSNU_CONTROL
SaveData [8] Save blemish correction data
to flash
LoadData [9] Load blemish correction data
from flash
ZeroData [10] see DSNU_CONTROL
--- [11..23] Reserved
GrabCount [24..31] see DSNU_CONTROL
Table 113: Advanced register: Blemish
Note
L
• See Chapter Input/output pin control on page 53
• See Chapter IO_INP_CTRL 1-2 on page 53
• See Chapter IO_OUTP_CTRL 1-2 on page 58
• See Chapter Output modes on page 59
