Configuration of the camera
MARLIN Technical Manual V2.4.0
193
580h ZOOM_INQ Always 0
584h PAN_INQ Always 0
588h TILT_INQ Always 0
58Ch OPTICAL_FILTER_INQ Always 0
590
..
5BCh
Reserved for other
FEATURE_LO_INQ
Always 0
5C0h CAPTURE_SIZE_INQ Always 0
5C4h CAPTURE_QUALITY_INQ Always 0
5C8h
..
5FCh
Reserved for other
FEATURE_LO_INQ
Always 0
600h CUR-V-Frm_RATE/Revision Bits [0..2] for the frame rate
604h CUR-V-MODE Bits [0..2] for the current video mode
608h CUR-V-FORMAT Bits [0..2] for the current video format
60Ch ISO-Channel Bits [0..3] for channel, [6..7] for ISO-speed
610h Camera_Power Always 0
614h ISO_EN/Continuous_Shot Bit 0: 1 for continuous shot; 0 for stop
618h Memory_Save Always 0
61Ch One_Shot, Multi_Shot,
Count Number See Chapter One-shot on page 123
See Chapter Multi-Shot on page 125
620h Mem_Save_Ch Always 0
624 Cur_Mem_Ch Always 0
628h Vmode_Error_Status Error in combination of Format/Mode/ISO Speed:
Bit(0): No error; Bit(0)=1: error
Register Name Field Bit Description
Table 92: Feature elements inquiry register
