Configuration of the camera
MARLIN Technical Manual V2.4.0
186
254h V_RATE_INQ
(Format_2, Mode_5)
FrameRate_0 [0] 1.875 fps
FrameRate _1 [1] 3.75 fps
FrameRate _2 [2] 7.5 fps
FrameRate _3 [3] 15 fps
FrameRate _4 [4] 30 fps
FrameRate _5 [5] 60 fps
FrameRate _6 [6] Reserved
FrameRate _7 [7] Reserved
--- [8..31] Reserved (zero)
258h V_RATE_INQ
(Format_2, Mode_6)
FrameRate_0 [0] 1.875 fps
FrameRate _1 [1] 3.75 fps
FrameRate _2 [2] 7.5 fps
FrameRate _3 [3] 15 fps
FrameRate _4 [4] 30 fps
FrameRate _5 [5] 60 fps
FrameRate _6 [6] Reserved
FrameRate _7 [7] Reserved
--- [8..31] Reserved (zero)
25Ch V_RATE_INQ
(Format_2, Mode_7)
FrameRate_0 [0] 1.875 fps
FrameRate _1 [1] 3.75 fps
FrameRate _2 [2] 7.5 fps
FrameRate _3 [3] 15 fps
FrameRate _4 [4] 30 fps
FrameRate _5 [5] 60 fps
FrameRate _6 [6] Reserved
FrameRate _7 [7] Reserved
--- [8..31] Reserved
260h
…
2BFh
Reserved V_RATE_INQ_y_x (for other Format_y, Mode_x)
2C0h V_REV_INQ_6_0 (Format_6, Mode0) Always 0
2C4h
..
2DFh
Reserved V_REV_INQ_6_x (for other Mode_x of Format_6) Always 0
Offset Name Field Bit Description
Table 89: Frame rate inquiry register
