Configuration of the camera
MARLIN Technical Manual V2.4.0
201
Advanced features (AVT-specific)
The camera has a variety of extended features going beyond the possibilities
described in IIDC V1.3. The following chapter summarizes all available
advanced features in ascending register order.
Advanced registers summary
The following table gives an overview of all available advanced registers:
Note
L
This chapter is a reference guide for advanced registers
and does not explain the advanced features itself. For
detailed description of the theoretical background see
• Chapter Description of the data path on page 65
• Links given in the table below
Register Register name Description
0XF1000010 VERSION_INFO Table 98: Advanced register: Version information
on page 204
0XF1000040 ADV_INQ_1 See Table 100: Advanced register: Advanced fea-
ture inquiry on page 206
0XF1000044 ADV_INQ_2
0XF1000200 MAX_RESOLUTION See Table 101: Advanced register: Maximum reso-
lution inquiry on page 207
0XF1000208 TIMEBASE See Table 102: Advanced register: Time base on
page 208
0XF100020C EXTD_SHUTTER See Table 104: Advanced register: Extended shut-
ter on page 210
0XF1000210 TEST_IMAGE See Table 105: Advanced register: Test image on
page 211
0XF1000220 SEQUENCE_CTRL except MARLIN F-131x
See Table 51: Advanced register: Sequence mode
on page 131
0XF1000224 SEQUENCE_PARAM
0XF1000240 LUT_CTRL See Table 107: Advanced register: LUT on page
213
0XF1000244 LUT_MEM_CTRL
0XF1000248 LUT_INFO
0XF1000250 SHDG_CTRL See Table 108: Advanced register: Shading on
page 214
0XF1000254 SHDG_MEM_CTRL
0XF1000258 SHDG_INFO
Table 97: Advanced registers summary
