Camera interfaces

MARLIN Technical Manual V2.4.0

60

Figure 27: Output Impulse Diagram

Note

L

The signals can be inverted.

Caution

a

Firing a new trigger while IntEna is still active can result in
image corruption due to double exposure occurring.
