Specifications
MARLIN Technical Manual V2.4.0
23
MARLIN F-046B/C
Feature Specification
Image device Type 1/2 (diag. 8 mm) progressive scan SONY CCD ICX-415AL/AQ
with HAD microlens
Chip size 7.48 mm x 6.15 mm
Cell size 8.3 µm x 8.3 µm
Picture size (max.) 780 x 582 (Format_7 Mode_0)
Lens mount C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)
mechanical flange back to filter distance: 8.2 mm
ADC 12 bit
Color modes Only color: Raw8, RGB8, YUV422, YUV411
Frame rates 3.75 fps; 7.5 fps; 15 fps; 30 fps; up to 52.81 fps in Format_7
Gain control Manual: 0-24 dB (0.035 dB/step); auto gain (select. AOI)
Shutter speed 32 µs …67.108.864 µs (~67s); auto shutter (select. AOI)
External trigger shutter Trigger_Mode_0, Trigger_Mode_1, advanced feature:
Trigger_Mode_15 (bulk); image transfer by command; trigger delay
Internal FIFO memory Up to 13 frames
Number of look-up tables One, user-programmable (10 bit 8 bit); gamma (0.5)
Smart functions Real-time shading correction image sequencing, image mirror (L-R
Q R-L), binning, secure image signature (SIS), user profiles
Two configurable inputs, two configurable outputs
RS-232 port (serial port, IIDC V1.31)
Transfer rate 100 Mbit/s, 200 Mbit/s, 400 Mbit/s
Digital interface IEEE 1394 IIDC V1.3
Power requirements DC 8 V - 36 V via IEEE 1394 cable or 12-pin HIROSE
Power consumption Less than 3 watt (@ 12 V DC)
Dimensions 72 mm x 44 mm x 29 mm (L x W x H); without tripod and lens
Mass <120 g (without lens)
Operating temperature +5 ... +45 °Celsius
Storage temperature -10 ... +60 °Celsius
Regulations CE, FCC Class B, RoHS (2002/95/EC)
Standard accessories b/w and color: IR cut filter
Optional accessories b/w: IR cut filter, IR pass filter
color: protection glass
Table 9: Specification MARLIN F-046B/C
