Video formats, modes and bandwidth
MARLIN Technical Manual V2.4.0
142
Owing to color interpolation, the maximum height is 1036 pixels in YUV
modes and the first and last pixel columns contain no image information.
Format Mode Resolution Color mode Maximal S400 frame rates for Format_7 modes
7
0 1392 x 1040
1392 x 1038
Mono8
Mono16
YUV411
YUV422
RGB8
RAW8
10 fps
10 fps
10 fps
10 fps
7.5 fps
10 fps
1 696 x 1040
1392 x 1040
Mono8
Mono16
Mono8 (RAW)
10 fps H-binning
10 fps H-binning
10 fps Raw Bayer pattern
2 1392 x 520
696 x 518
Mono8
Mono16
YUV411
YUV422
RGB8
RAW8
17 fps V-binning
17 fps V-binning
10 fps H+V sub-sampling
10 fps H+V sub-sampling
10 fps H+V sub-sampling
10 fps H+V sub-sampling
3 696 x 520 Mono8 17 fps H+V binning
Table 59: Video Format_7 default modes Marlin F-145B / F-145C
