Video formats, modes and bandwidth
MARLIN Technical Manual V2.4.0
148
* : Color camera outputs RAW image, which needs to be converted outside of camera.
*: With minimum shutter; increasing shutter will decrease max. frame frequency proportionally due to
global shutter principle.
**: With shutter
≤ 23 ms only
***: With shutter
≤ 18ms only.
Format Mode Resolution Color mode Maximal S400 frame rates for Format_7 modes
7
0 1280 x 1024
1280 x 1020
Mono8
YUV411
YUV422
25 fps*
17 fps*
12 fps*
1 640 x 1024
640 x 1020
Mono8
YUV411
YUV422
48 fps* H-sub-sampling
33 fps*
25 fps*
2 1280 x 512
1280 x 508
Mono8
YUV411
YUV422
50 fps* V-sub-sampling
33 fps*
25 fps*
3 640 x 512
640 x 508
Mono8
YUV411
YUV422
94 fps* H+V sub-sampling
64 fps*
50 fps*
4 1280 x 1024 Mono8 25 fps*
Table 65: Video Format_7 default modes Marlin F-131B / Marlin F-131C (NIR)
Note
L
Generally full resolution mono frame rates are achievable
only with shutter settings which fulfil the equation:
Shutter
≤ 1/fps- 40ms
