Introduction
MARLIN Technical Manual V2.4.0
14
• Chapter Camera interfaces on page 48 describes in detail the inputs/
outputs of the cameras (incl. Trigger features). For a general descrip-
tion of the interfaces (FireWire and I/O connector) see Hardware
Installation Guide.
• Chapter Description of the data path on page 65 describes in detail IIDC
conform as well as AVT-specific camera features.
• Chapter Controlling image capture on page 113 describes trigger modi,
exposure time, one-shot/multi-shot/ISO_Enable features. Additionally
special AVT features are described: sequence mode and secure image
signature (SIS).
• Chapter Video formats, modes and bandwidth on page 137 lists all avail-
able fixed and Format_7 modes (incl. color modes, frame rates, bin-
ning/sub-sampling, AOI=area of interest).
• Chapter How does bandwidth affect the frame rate? on page 166 gives
some considerations on bandwidth details.
• Chapter Configuration of the camera on page 171 lists standard and
advanced register descriptions of all camera features.
• Chapter How does bandwidth affect the frame rate? on page 166
explains where to get information on firmware updates and explains the
extended version number scheme of FPGA/µC.
• Chapter Appendix on page 237 lists the sensor position accuracy of AVT
cameras.
• Chapter Index on page 238 gives you quick access to all relevant data in
this manual.
Conventions used in this manual
To give this manual an easily understood layout and to emphasize important
information, the following typographical styles and symbols are used:
Styles
Style Function Example
Bold Programs, inputs or highlighting
important things bold
Courier Code listings etc. Input
Upper case Register REGISTER
Italics Modes, fields Mode
Parentheses and/or blue Links (Link)
Table 2: Styles
