Page 231

Specifications
231
9.2 Arbitrary Waveform Generator
Specifications
Note: The specifications in this section apply to models
2540B-GEN and 2542B-GEN only.
Frequency Characteristics
Sine waveform
1
μHz to 20 MHz (2540B-GEN)
1
μHz to 40 MHz (2542B-GEN)
Square waveform
1
μHz to 20 MHz
Pulse waveform
1 mHz to 10 MHz
Built-in AWG
1 mHz to 1 MHz
User AWG
1 mHz to 1 MHz
Frequency resolution
Sine, Square: 1
μHz
Pulse, Built-in ARB, User ARB: 1 mHz
Frequency accuracy
≤ ± 5 x 10
-4
Frequency stability
± 5 x 10
-5
Waveform Characteristics
Harmonic Distortion
< 5 MHz: -50 dBc
≤10 MHz: -45 dBc
>10 MHz: -40 dBc
Total harmonic
20 Hz to100 kHz:
≤ 0.2%
