Menu Operation
126
Persistence softkey under the DISPLAY menu.
See “DISPLAY Menu” for details.
Saving/Loading Setups
Press SAVE/LOAD
→Internal Storage→Storage type to
display the INTERNAL menu and select Setups storage type.
Softkey
Options
Description
Storage
type
Traces
Trace file format
Setups
Setup file format
Setupxx
Select a setup file from
Setup01 to Setup10
Save
----
Save the current
configuration to the current
setup file
Load
----
Load from the current setup
file
----
Return to the SAVE/LOAD
menu
Note: Each setup stores all the horizontal, vertical, and
trigger control settings. This includes and not
limited to horizontal timebase, horizontal position,
vertical scale, vertical position, and trigger
position.
