Quick Start Guide
212
2. Press the MENU key and select Output Type to be
User ARB.
3. Then, select More 1/2 softkey and select
Capture/Storage softkey.
4. Press the Source softkey and select A+B.
Note: This selection will change depending on the
Operate parameter set under MATH menu.
5. Select Data Type as Period Data if you want to store
a complete period of the CH1+CH2 waveform, or
select Screen Data to capture only what’s displayed
on the screen.
6. Then press Internal Storage and change Storage
Pos to the memory location to store the waveform to.
7. Press Save and the CH1+CH2 waveform will be
saved into internal arbitrary waveform memory, which
can be recalled and output.
Note: The captured Math waveform will be limited to
600 points, and some scaling is done internally.
See the “Capture/Storage” section for details.
