Specifications
229
Acquisition system
Max real time
sample rate
1 GSa/s
Max equivalent
sample rate
50 GSa/s
Max memory depth
(Based on Sample rate)
1 GSa/s: 16 kpts
500 MSa/s: 8 kpts (dual channel)
500 MSa/s: *2.4 Mpts (single channel)
≤ 250 MSa/s: *1.2 Mpts (single and dual channel
operation)
Vertical resolution
8 bits
Sample mode
Normal, Average, Peak Detect
Autoset
Finds and displays all active channels, sets edge
trigger mode on channel 1, set vertical sensitivity
on scope channels and time base to display one
or five periods.
Requires minimum voltage >10 mVpp, 0.5% duty
and minimum frequency >50 Hz.
*Maximum number of points can only be extracted via remote
control using the USB, RS232C, or LAN interface.
