6.2 Capture Single Shot Signal
Digital Storage Oscilloscope can easily be used to capture a
single-shot or unrepeatable signal. Perform the following
steps to capture a single-shot signal.
Connect the channel 1 probe to the unknown signal.
Press the trigger MENU key to display the TRIGGER
menu.
Press the Source softkey to select CH1.
Press the Mode softkey to select the Auto trigger mode.
Adjust the vertical and horizontal controls to observe the
signal roughly and find out the right Trigger Type and
Trigger mode.
Press the Type softkey from the TRIGGER menu page
to select Pulse trigger type.
Press More 1/2 sofkey to display the TRIGGER menu
page 2/2.
Press Mode softkey to select Normal Trigger mode.
Press More 2/2 sofkey to display the TRIGGER menu
page 1/2.
Press Pulse Mode softkey to select
(positive less
than).
Rotate the entry knob (
) to set up the pulse width.
