MKP 3000 Series • Reference Information

MKP 3000 Series • Reference Information

Reference Information

A-3

Enclosure .................. 2.7" H x 3.4" W x 2.0" D

(6.7 cm H x 8.6 cm W x 5.1 cm D)
Allow at least 1" (2.5 cm) D for connectors
and cable.
(Depth excludes connectors.)

MKP 3000 MAAP

Plate ........................... 4.5" H x 6.4" W x 0.1" D (3 gang)

(11.4 cm H x 16.3 cm W x 0.3 cm D)

Circuit board ............ 2.8" H x 2.2" W x 1.3" D

(7.1 cm H x 5.6 cm W x 3.3 cm D)

MKP 3000 L

Plate ........................... 3.15" H x 6.5" W x 0.1" D

(8.0 cm H x 16.5 cm x 0.3 cm D)

Circuit board ............ 2.8" H x 2.2" W x 1.3" D

(7.1 cm H x 5.6 cm W x 3.3 cm D)

Product weight ............................. 0.5 lbs (0.3 kg)
Shipping weight ........................... 2 lbs (1 kg)
Vibration ....................................... ISTA 1A in carton (International Safe

Transit Association)

Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%.

Specifications are subject to change without notice.

A-2

Specifications

Control/remote — keypad

Serial control port ........................ (2) RS-232 on (2) 3.5 mm, 3-pole captive

screw connectors

Baud rate and protocol ............... Variable (9600 to 115200 baud), 9600 baud

(default), 8 data bits, 1 stop bit, no parity

Serial control pin configurations 1 = TX, 2 = RX, 3 = GND
Ethernet control port ................... 1 RJ-45 female connector
Ethernet data rate ........................ 10/100Base-T, half/full duplex with

autodetect

Ethernet protocol ......................... ARP, DHCP, ICMP (ping), TCP/IP,

Telnet, HTTP, SMTP

client

Ethernet default settings ............ Link speed and duplex level =

autodetected
IP address = 192.168.254.253
subnet mask = 255.255.0.0
default gateway = 0.0.0.0
DHCP = off

Program control ........................... Extron’s Simple Instruction Set (SIS

)

Microsoft

®

Internet Explorer, Telnet

General

External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, external,

autoswitchable; to 12 VDC, 1 A, regulated

Power input requirements ......... 12 VDC, 400 mA
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) /

10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing

Rack mount

MKP 3000 .......................... No, but furniture mountable, and wall

mountable in a wall box or mud ring

MKP 3000 L ...................... Yes, with optional UCM RAAP mounting

plate; also furniture mountable

Enclosure type .............................. Metal
Enclosure dimensions

MKP 3000

Plate ........................... 4.5" H x 4.6" W x 0.1" D (2 gang)

(11.4 cm H x 11.7 cm W x 0.3 cm D)
