Precautions, cont’d
MKP 3000 Series • Quick Start Guide
Quick Start Guide — MKP 3000
QS-1
Install and set up the MKP 3000 as follows:
Step 1
Turn all of the equipment off or disconnect it from its power source.
Step 2
Install the cables that will run to and from the control panel in a
wall, podium, or desk.
Step 3
Prepare the wall, podium, desk, or other surface to mount the MKP .
See “Preparing the site and installing the mounting bracket (mud
ring) or wall box” in chapter 2, “Installation.”
Step 4
Install the control panel in a wall, podium, desk, or other surface.
See “Installation Procedures” in chapter 2, “Installation.”
Step 5
Connect the input and output cables . See “Rear Panel and Side
Panel Connections” in chapter 2, “Installation,” for guidelines.
Step 6
Connect the power supply . See “Power supply wiring” in chapter 2,
“Installation.”
Step 7
Connect power cords and turn on the equipment in the following
order: output devices (such as projectors or monitors), the connected
matrix switcher, and input devices (such as DSSs or cable boxes).
Step 8
If necessary, set the IP parameters of the control panel and matrix
switcher
. See “Viewing and configuring the IP and MKP setup
parameters” in chapter 3, “Local Operation;” or “System Settings
page” in chapter 5, “HTML Operation.”
Step 9
If necessary, set the control panel’s RS-232 port for pass-through or
no-pass-through mode, and specify whether the MKP is the primary
device (connected to the switcher) or secondary device (connected
through another device). See “Viewing and configuring the IP and
MKP setup parameters” in chapter 3, “Local Operation,” or “System
Settings page” in chapter 5, “HTML Operation.”
