MKP 3000 Series • SIS

Operation

MKP 3000 Series • SIS

Operation

SIS

Operation, cont’d

4-9

X22

= Daylight Savings Time

0 = Daylight Savings Time off/ignore
1 = Daylight Savings Time on
(northern hemisphere)
2 = Daylight Savings Time on
(Europe)
3 = Daylight Savings Time on (Brazil)

X23

= IP address

###.###.###.###

X24

= Hardware (MAC) address ##-##-##-##-##-##

X25

= Connection priority

0 = Primary
1 = Secondary

X26

= Password

12 digits, alphanumeric

The following characters are invalid in passwords:
{space} + ~ @ = ‘ [ ] { } < > ’ “ ; : | \

and ?.

X27

= Web page priority

0 = Internal (default on power up)
1 = User

X28

= Executive mode

0 = Administrator mode (panel

unlocked)

1 = User mode
2 = Panel locked

X29

= Tie mode

0 = Matrix mode
1 = Input-only mode

4-8

Command/r

esponse table for MKP SIS commands

Command

ASCII Command

Response

Additional description

(host to MKP)

(MKP to host)

F

ront panel security lockout (executive mode)

Panel locked mode

2x

Exe2

Lock fr

ont panel.

User mode

1x

Exe1

Enable only input, output, pr

eset, and volume

selection fr

om the front panel.

Administrator mode

0x

Exe0

Unlock front panel.

V

iew front panel lock status

x

X2

8

Show front panel lock status. For

X2

8

:

0 =

Administrator mode (panel unlocked).

1 = User mode.

2 = Panel locked.

Pass-through (RS-232 port r

edir

ect)

Configur

e r

edirect mode

Esc

X2

*

X3

*

X4

*

X5

CD

Cpn

X2

Ccd

X3

,

X4

,

X5

T

urn redirect mode on.

Example

:

Esc

1*2*50*10D*CD

Cpn01• Ccd00002,00050,00000L

Redir

ect port 1 to port 2. W

ait 500 ms for r

esponse.

The “L” or “D” delimiter in value

X5

is case sensitive and must be upper

case.

Disable redir

ec

t

Esc

X2

*

0CD

Cpn

X2

Ccd00000,00000,00000L

V

iew redire

ct

Esc

X2

CD

X3

,

X4

,

X5

V

iew redirect mode on/of

f status.

Information r

equests

Information

request

I

MKP

3000 •

LCD •

KEYP

AD or MKP

3000 •

LCD

Request for part number

N

60-7xx-00

MKP 3000 and MKP 3000 MAAP without MKP 10:

60-708-00

MKP 3000 L: 60-709-00

MKP 3000 MAAP with MKP 10: 60-710-00
