MKP 3000 Series • SIS

Operation

MKP 3000 Series • SIS

Operation

SIS

Operation, cont’d

X11

= Baud rate

300, 600, 1200, 1800, 2400, 3600, 4800,
9600 (default), 14400, 19200, 28800,
38400, 57600, or 115200

X12

= Parity (1st character only) Odd, Even, None (default), Mark,

S

pace

X13

= # of data bits

7, 8 (default)

X14

= # of stop bits

1 (default), 2

X15

= Input or output number

0 through 999

X16

= Name

11 characters maximum for inputs
and outputs
12 characters maximum for presets
24 characters maximum for MKP
name.
Upper- and lowercase alphanumeric
characters, spaces, and / are valid.

The following characters are invalid in the name:
+ ~ , @ = ‘ [ ] { } < > ’ “ ; : | \

and ?.

X17

= Preset number

X18

= Default name

Factory default name
(combination of the model name
+ last 3 pairs of MAC address).

X19

= Time and date (set)

MM/DD/YY-HH:MM:SS
where:
MM = month: 01 (Jan.) — 12 (Dec.)
DD = day: 01 through 31
YY = year: 00 through 99
HH = hour: 00 through 24
MM = minutes: 00 through 59
SS = seconds: 00 through 59

X20

= Time and date (read)

Day,•DD•Mmm•YYYY•HH:MM:SS
where:
Day = weekday: Mon through Sun
DD = day: 01 through 31
Mmm = month: Jan through Dec
YYYY = year: 2000 through 2099
HH = hour: 00 through 24
MM = minutes: 00 through 59
SS = seconds: 00 through 59

X21

= GMT offset

–12.0 through +14.0. Hours and
minutes removed from GMT

4-7

Symbol definitions

= CR/LF (carriage return/line feed)

= CR (carriage return — no line feed)

= space

X1

= On/off status

0 = off/disable
1 = on/enable

X2

= RS-232 port number

1 = host
2 = switcher

X3

= n = –1= redirect serial port data from the specified port to allow

for a transparent pass through mode. The response is returned
with leading zeroes.
n = the maximum number of serial ports that the IP link supports.

X5

is verified at this port.

X4

= Time (in 10 ms increments) to wait for receive data before

releasing the port to another source (min = 1 [10 ms],
maximum = 32767 [32.767 seconds], default = 10 [100 ms]).

X5

= Numerical value (nnnn) to set L (length of message to receive) or

assign as a D (delimiter).
L

= number of byte count (min = 0, max = 32767, default = 0).

D

= decimal number for ASCII character (min = 0,

maximum = 00255, default = 00000L).

The numeric value directly precedes the identifier; for example:

X5

= “3L”

to specify a 3-byte length or

X5

= “10D” to specify an ASCII delimiter of

0A. The identifier, “L” or “D” is case sensitive and must be uppercase.

X6

= Firmware version

Bootstrap version (x.xx)

X7

= Verbose firmware version-description-upload date/time. See

page 4-10.

X8

= Voltage 1 (3.3 V), Voltage 2 (12.0 V),

Temperature (degrees Fahrenheit)
(xxx.xx), Voltage 3 (5.0 V)

X9

= Verbose/response mode

0 = no password assigned
1 = verbose mode
2 = tagged responses for queries
3 = 1 and 2 (verbose and tagged)

The default

X9

value is 0 for Telnet and 0 for RS-232.

If tagged responses are enabled, all read commands return the constant
string plus the data, the same as setting the value. For example, the MKP
responds
Ipn•

X18

to the

Esc

•CN

command.

X10

= Security level

0 = clear/none
11 = user password assigned
12 = administrator password assigned

4-6
