2-9

MPX Plus 866 A Media Presentation Matrix Switcher • Installation

PRELIMINAR

Y

Reset button

n

Reset button and LED — The Reset button initiates four levels

of reset to the matrix switcher. The LED indicates the reset mode

activated. Press and hold the button while the switcher is running or

while you power up the switcher for different reset levels.

See “Rear panel Operations” in chapter 3, “Operation”, for details.
Events (mode 3) reset — Toggles events monitoring on and off.
IP settings (mode 4) reset — Resets the switcher’s IP functions.

N

IP settings reset does not replace any user-installed firmware.

Absolute (mode 5) reset — Restores the switcher to the default factory

conditions.

Hard (mode 1) reset — Restores the switcher to the base firmware.

N

Hard reset does not clear the current configuration.

Power

o

AC power connector — Plug a standard IEC power cord into this connector to

connect the switcher to a 100 VAC to 240 VAC, 50-60 Hz power source.

RESET
