Reference Information, cont’d
MPX Plus 866 A Media Presentation Matrix Switcher • Reference Information C-8
PRELIMINAR
Y
VGA male-to-male with audio cables Part number
VGA-A M-M MD , 3' to 100' (0.9 m to 30.4 m) (molded) 26-490-nn
VGA-A M-M BK , 3' to 100' (0.9 m to 30.4 m) (backshell) 26-490-nn
VGA-A 90º M-M MD , 3' to 12' (0.9 m to 3.6 m) (molded) 26-510-nn
VGA-A 90º M-M BK , 3' to 12' (0.9 m to 3.6 m) (backshell) 26-510-nn
VGA-A 90º Up M-M MD , 3' to 12' (0.9 m to 3.6 m) (molded) 26-510-nn
VGA-A 90º Up M-M BK 3' to 12' (0.9 m to 3.6 m) (backshell) 26-510-nn
VGA male-to-female cables Part number
VGA M-F MD , 3' to 100' (0.9 m to 30.4 m) (molded) 26-112-nn
VGA M-F BK , 3' to 100' (0.9 m to 30.4 m) (backshell) 26-112-nn
VGAP M-F MD , plenum 3' to 25' (0.9 m to 7.6 m) (molded) 26-438-nn
VGAP M-F BK , plenum 35' to 100' (10.6 m to 30.4 m)
(backshell)
26-438 -nn
VGA male-to-female with audio cables Part number
VGA-A M-F MD , 3' to 50' (0.9 m to 15.2 m) (molded) 26-491-nn
VGA-A M-F BK , 3' to 50' (0.9 m to 15.2 m) (backshell) 26-491-nn
VGA-A 90º M-F MD , 3' to 12' (0.9 m to 3.6 m) (molded) 26-509-nn
VGA-A 90º M-F BK , 3' to 12' (0.9 m to 3.6 m) (backshell) 26-509-nn
VGA-A 90º Up M-F MD , 3' to 12' (0.9 m to 3.6 m) (molded) 26-509-nn
VGA-A 90º Up M-F BK 3' to 12' (0.9 m to 3.6 m) (backshell) 26-509-nn
S-video cables Part number
MHR-2 SVM-M , 6' to 100' (1.8 m to 30.4 m) 26-316-nn
MHR-2P SVM-M , Plenum, 6' to 100' (0.9 m to 30.4 m)) 26-522-nn
S-video/BNC adapters Part number
SVHSF-BNCM , S-video female to BNC male, 1' to 6'
(30 cm to 1.8 m)
26-541-nn
SVHSF-BNCF , S-video female to BNC female, 8" (20 cm) 26-541-01
SVHSM-BNCF , S-video male to BNC female, 1' to 6'
(30 cm to 1.8 m)
26-353-nn
SVHSM-BNCF , S-video female to BNC female, , 8" (20 cm) 26-353-01
Composite video male-to-male cables
RG6 BNC
, 3' to 100' (0.9 m to 30.4 m) 26-383-nn
