MPX Plus 866 A Media Presentation Matrix Switcher • DSP SIS Commands
PRELIMINAR
Y
Command/response table for DSP SIS commands
Command
ASCII command
(host to switcher)
Response
(switcher to host)
Additional
description
Audio trim, gain, and mixing
N
• The DSP level adjustments are completely separate from the input gain and attenuation (G and g commands) and the
output volume (V) commands available in the basic SIS commands.
• The command format is the same, regardless of the control or mix-point that is to be set; the acceptable adjustment
range varies depending on the control or mix-point:
The program audio input (pre-matrix) trim range is -12 dB to +12 dB, in 0.1 dB increments.
The mic/line input gain range is 0 dB to 80 dB, in 1.0 dB increments.
The post-matrix level trim is -12 dB to +12 dB, in 0.1 dB increments.
The mic mix-points (with their associated mixing controls) range is -35 dB to +25 dB, in 0.1 dB increments.
• All responses are shown with the matrix switcher in Verbose mode 2 or 3.
Set a DSP trim or mix
(excluding mic/line inputs)
E
G
X6)
*
X6!
AU
}
DsG
X6)
*
X6!]
Set DSP trim or mix control
X6)
to a value of
X6!
dB.
Example 1 (trim control):
E
G30124*2040AU
}
DsG30124*2040
]
Set the input 13, left audio
trim to a value of -0.8 dB.
Example 2 (mix control):
E
G21308*2213AU
}
DsG21308*2213
]
Mix +16.5 dB of mic 2 into
output 5, left.
Set a mic/line gain
E
G
X6)
*
X6@
AU
}
DsG
X6)
*
X6@]
Set mic/line gain control
X6)
to a value of
X6@
dB.
Example:
E
G40001*2288AU
}
DsG40001*2288
]
Set the mic/line input 2 gain
to a level of +24.0 dB.
Read a DSP trim or mix
(excluding mic/line inputs)
E
G
X6)
AU
}
DsG
X6)
*
X6!]
DSP trim or mix control
X6)
is set to a value of
X6!
dB.
Example 1
(post matrix gain control):
E
G50007AU
}
DsG50007*2103
]
Output 4, post matrix gain is
set to a value of +5.5 dB.
Example 2 (mix control):
E
G21211AU
}
DsG21211*2140
]
+9.2 dB of mic 1 is mixed
into output 6, right.
Read a mic/line gain
E
G
X6)
AU
}
DsG
X6)
*
X6@]
Mic/line gain control
X6)
is
set to a value of
X6@
dB.
Example:
E
G40000AU
}
DsG40000*2598
]
Mic/line input 1 gain is set
to a value of +55.0 dB.
Audio mute
N
• Only mic/line input gain blocks (
b
) and mic mix-points (
d
) can be muted.
• All responses are shown with the matrix switcher in Verbose mode 2 or 3.
Audio mute
E
M
X6)
*1AU
}
DsM
X6)
*
1
]
Mute audio point
X6)
.
Example:
E
M21410*1AU
}
DsM21410
*
1
]
Mute output 6, left, mic 3.
Audio unmute
E
M
X6)
*0AU
}
DsM
X6)
*
0
]
Unmute audio point
X6)
.
Read audio mute or level
E
M
X6)
AU
}
DsM
X6)
*
X6#]
X6#
: 0 = mute off, 1 = mute on.
N
X6)
= Gain control or mic mix-point See the tables on page B-4 and B-5.
X6!
= Level value
See the tables on page B-6 through B-8.
X6@
= Mic/line gain level value
See the table on page B-8.
X6#
= Mute status
0 = unmute
1 = mute
