Keyboard navigation
The DSP Configurator program is fully navigable using the computer keyboard.
Some keyboard navigation behavior matches Windows standards, while other
behaviors are specific to the DSP Configurator program.
When the program is started, the cursor focus is in the upper left corner of the
program audio input (computer/audio group and video/audio group signal
processor chains (
a
on figure 5-20). The Input 1 Gain block is green highlighted
[ ]).
N
The callout numbers on figure 5-20 are not the same as on figure 5-3.
7
1
10
6
11
3
4
5
8
2
Figure 5-20 — DSP Configurator program window
