photoLab
®
6100 VIS Operation
81 ba75847e01 08/2009
4.8.2 Recording the Spectrum
A message containing operating
instructions is displayed.
1 Open the setting menu with
[Setup].
2 Select the start and end point of
the spectrum to be recorded and
the mode (Absorbance or
Transmission).
3 Accept all entries with [Apply].
A message containing operating
instructions is displayed.
Spectrum
Spectrum 04/16/07 9:52
Wavelength [nm]
Setup Open
Ab
so
rb
an
ce
Spectrum
You have to record a baseline first
().
Adjustment of wavelength range under
.
Spectrum 04/16/07 9:52
Wavelength start 320 nm
Wavelength stop 1100 nm
Mode Absorbance
Cursor All values
Smoothing Yes
Scaling Auto
Apply
Spectrum 04/16/07 9:52
Wavelength [nm]
Setup Open
Ab
so
rb
anc
e
Spectrum
You have to record a baseline first
().
Adjustment of wavelength range under
.
