Test record

A test record is displayed after the check. It can be printed and stored as a
file (in the internal DataB folder or USB memory device at the USB-A
connection, see section 4.11.1).

Sample printout:

Note
Afterwards you can view the last AQA1 test record under AQA1 info.

Insert the cell.
The cuvette is automatically
recognized and the measurement
started.

After measuring, the
measurement result, Target value,
Tolerance and an evaluation (OK
or failed) are displayed.

The photometer offers to repeat
the measurement if the check
failed.

If the check was successful, the
measurement of the next
PhotoCheck test standard, e.g.
445/2, appears on the display.

Measure all test standards in the
same way.
After all test standards are
successfully measured, the check
is passed.

PhotoCheck 445/1

04/16/07 9:52

Please insert PhotoCheck 445/1

SpectroFlex 6100

09130512 1.30-WTW-1.60 Administrator

AQA1

Protocol ID

Executed by:

Administrator

Executed

22.05.2007

Valid until:

26.06.2007

PhotoCheck

OC479094

445-1

0.200 +- 100

0.192

445-2

0.500 +- 200

0.511

445-3

1.000 +- 200

1.006

445-4

1.500 +- 200

1.526

525-1

0.200 +- 200

0.247

.....

............

.....

............

.....

(etc.)
