Page 2 of 6:
Add another wavelength with
[Add].
Delete the last wavelength with
[Delete].
4
Using [Next], accept all entries on
the page and switch to the next
page.
5
Page 3 of 6:
Enter the coefficients for the basic
equation (more detailed
information of the basic equation,
see section 4.7.1).
6
Using [Next], accept all entries on
the page and switch to the next
page.
7
Page 4 of 6:
Enter the coefficients for the basic
equation (more detailed
information of the basic equation,
see section 4.7.1).
8
Using [Next], accept all entries on
the page and switch to the next
page.
9
Page 5 of 6:
The data is displayed once again
as a summary.
Using [Back], you can correct
wrong data on the previous pages.
Using [Next], accept all entries on
the page and switch to the next
page.
The method is programmed and
selected.
Edit method (2 of 6)
04/16/07 9:52
Wavelength 1
280 nm
Wavelength 2
260 nm
Back
Add
Delete
D
Next
Edit method (3 of 6)
04/16/07 9:52
a0 + a1 * A1 + a2 * A2 + ... + a10 * A10
R=
b0 + b1 * A1 + b2 * A2 + ... + b10 * A10
a0
0.000 a6
0.000
a1
1.550 a7
0.000
a2
-0.757 a8
0.000
a3
0.000 a9
0.000
a4
0.000 a10
0.000
a5
Back
Next
Edit method (4 of 6)
04/16/07 9:52
a0 + a1 * A1 + a2 * A2 + ... + a10 * A10
R=
b0 + b1 * A1 + b2 * A2 + ... + b10 * A10
b0
1.000 b6
0.000
b1
0.000 b7
0.000
b2
0.000 b8
0.000
b3
0.000 b9
0.000
b4
0.000 b10
0.000
b5
Back
Next
Edit method (5 of 6)
04/16/07 9:52
Number:
2002
Name:
PROT
Version:
1.0
Citation form:
Protein
Unit:
mg/ml
Resolution:
0.001
Cell:
10 mm
Back
D
Next
