Operation photoLab
®
6100 VIS
100 ba75847e01 08/2009
4.10.1 User defined timer
If you want to manually enter time intervals, use the User defined timer
function.
4.10.2 Analysis timer
Between the individual steps of a measurement, reaction times often have to
be observed. The length of the reaction time is defined in the relevant
analysis instructions.
For all required reaction times, the analysis timers with the corresponding
time intervals are stored in the instrument. The names of the analysis timers
include the method name and a current number so several timers within a
method can be distinguished from each other.
To be able to use an analysis timer for a method you have to load it in the
timer overview first.
To do so, first select the required method and then add the available analysis
timers to the timer overview so they can be started as necessary.
The timer overview always comprises the free timer and the selected analysis
timers.
The Timer menu is open.
1 Highlight the User defined timer.
2 If necessary, change the name
and time of the timer with [Edit].
3 Start the highlighted timer with
[Start].
The status of the timer is Active.
When the specified time interval
has expired, an acoustic signal
sounds and the status changes to
Expired.
4 Stop the highlighted timer with
[Stop].
The status of the timer changes to
Inactive. The acoustic signal is
switched off.
Timer 04/16/07 9:52
Designation Time Status
User defined timer 00:15:00 Inactiv
A6/25 - 1 00:15:00 Inactiv
Start Stop Edit Add
