photoLab
®
6100 VIS Operation
79 ba75847e01 08/2009
Rectangular cell:
Open the inner turn-up lid.
Insert the rectangular cell
vertically so it touches the bottom
and left edge of the cell shaft. The
opaque sides of the rectangular
cell must point to the front and
back.
The photometer has an external
light recognition. If there is too
much external light, a message
prompts you to close the cell shaft
cover.
If necessary, carry out a zero
measurement.
The photometer is ready to
measure.
The photometer starts measuring
automatically.
If necessary, switch over to
transmission display (%) with
[Transmission].
Multi wavelengths 04/16/07 9:52
Zero adjustment successful
2001:PROT 10 mm
Setup Method list Transmission
Multi wavelengths 04/16/07 9:52
To start measurement,
insert cell or press
2001:PROT Protein
10 mm
Setup Method list Transmission
Multi wavelengths 04/16/07 9:52
A(280 nm) = 2.220 A(260 nm) = 0.925
2.738
mg/ml
2002: PROT Protein
10 mm
Setup Method list Transmission
