Operation
photoLab
®
6100 VIS
32
ba75847e01
08/2009
Note
During mere number entries (such as entering a wavelength), the keys of the
alphanumeric keypad are assigned to the respective numeral only. Each
keypressing directly enters the numeral (like a pocket calculator).
Special characters
Special characters are entered with the <1/*> key.
Operating example:
Entering the ID
The Enter ID input field appears if you press the
storing symbol is visible. In the following example a measurement dataset
with the ID "Test" is stored.
Correcting incorrect
entries
Using <
W>, erase all characters until you have reached the incorrect digit and
repeat the entry from there.
1
Press <8/TUV> several times until
"T" appears in the input line.
Below the input field, a selection
line pops up with all characters
that are available for this key, e.g.
8 T U V t u v.
The currently selected character is
highlighted.
After approx. one second the
character is taken over and the
selection line closed.
2
Complete the ID with
confirm.
Enter ID
8
8
T U V t u v
Enter ID
T
8
T
T U V t u v
Enter ID
Test_
